SPECIFICATIONS

Application: Desktop
Brand Name: Colorful
Chip Process: 16nm
Chipset Manufacturer: NVIDIA
Cooler Type: Triple Fans
High-concerned chemical: None
Interface Type: PCI Express 3.0x16
Memory Clock(Mhz): 8008
Origin: Mainland China
Output  Interface Type: DVI-D,HDMI 1.4x1,DisplayPort x1
Overclocked: No
Power Connector: 6pin + 6pin
Product Category: Desktop Graphics Cards
Product Features: NVLINK
RGB: No
Usage Scenario: Gaming,Audio & Video,Office
Video Memory Type: GDDR5

Graphics cards are the core
Chipmaker NVIDIA
Graphics card chip GeForce GTX 1070
Display chip series NVIDIA GTX 10 series
Production process 16 nanometers
Core codename GP104-200
Core Frequency Base Frequency: Base: 1506MHz; Boost:1683MHz
One-click OC core frequency: Boost: 1759MHz; Base:1569MHz
CUDA cores 1920
Video memory specifications
Video memory frequency 8008MHz
Video memory type GDDR5
The video memory capacity is 8GB
The memory bit width is 256 bits
Maximum resolution 7680×4320
Graphics card interface
Interface type PCI Express 3.0 16X
I/O Interfaces 1× HDMI interface, 1× DVI interface, 3× DisplayPort interface
Power Interface 6pin 6pin
Other parameters
Graphics card type mainstream
Heat dissipation method 3. Fan heat dissipation Heat pipe heat dissipation
3D API DirectX 12，OpenGL 4.5
Power supply mode 6 2 phases
Support for HDCP is
Maximum power consumption of 150W
Recommended power supply 500W
Other Features Support NVIDIA SLI technology
